one world mark

Engineering CACR implants HVAC Systems for the Pharmaceutic Complex

Altana Pharma Ltda, belongs to the Altana AG Group, Germany, produces medicines for the domestic and external market. In Brazil since 1974, Altana is one of the 20th main pharmaceutical industries of the country.

The Pharmaceutic complex, inaugurated in February 2002, occupies an area of 214 thousand m2, possesses nine interlinked buildings, with built area of 36 thousand m2, 18.500 m2 totally acclimatized and 5.260 m2 of Clean Rooms with cooling capacity of 1.800 TR (Tons of Refrigeration).

The project was idealized under the concept "Central Spin", a structure with 250 meters in length, that unifies all of the areas of the complex, with processes totally automated and perfectly integrated. The productive area is composed by three levels of hygiene classification C1, C2 and C3. When entering in any room, we recognized the classification for the coloration of the floor that is going from clear to dark blue for the controlled areas.

The risk of cross contamination is eliminated by a cascade of differential pressures and air locks.

The HVAC System, in total accordance with US FDA's recommendations (US Food and Drug Administration) and Regulations of Anvisa (National Agency of Sanitary Surveillance), have considered all requirement of the processes, the thermal comfort, the elimination of the risks of contamination and the environment protection. Focused in the rational use of energy, during programmed stops or days of rest the HVAC system reduces his energy consumption for 30% of the nominal without losing the cascade of pressures and the Validation of the process.

To reach all of the pharmaceutical complex requirements, Altana Pharma counted with the support and technology of CACR PHARMA LINE and the investments, brought to Brazil one of the largest industrial complexes, that became an world mark for the pharmaceutical industry.

The HVAC Systems supplied to Altana Pharma received the award "Destaques do ano 2002" of Smacna" Sheet Metal and Air Conditioning National Association" whose objective is to distinguish and to recognize in national extent the projects that stand out in the previous year for their Quality, characteristics and contributions for the thermal engineering
